BAS 8752
Mittelland Canal Bridge
30.04.2006
© Frank Sellke / brueckenweb.de
Use in accordance with the terms and conditions
30.04.2006
© Frank Sellke / brueckenweb.de
Use in accordance with the terms and conditions
30.04.2006
© Frank Sellke / brueckenweb.de
Use in accordance with the terms and conditionsGermany
Lower Saxony
Braunschweig
Mittelland Canal
Road B4
Arch bridge, arch under the roadway
Steel composite
2000 bis 2003
110.00 m
650.00 m
14.50 m
0.00 m
0.00 m
11600.00 m2
in operation
Steel truss bridge with concrete deck
strongly curved plan (radius 800 m), northern approach bridge L=150 m as a prestressed concrete slab girder; southern approach bridge as a composite steel truss with concrete slab (length 250 m)
strongly curved plan (radius 800 m), northern approach bridge L=150 m as a prestressed concrete slab girder; southern approach bridge as a composite steel truss with concrete slab (length 250 m)
NLStBV - GB Wolfenbüttel
3629552
